Electrical Services

Our Electrical Services consists of single and three phase circuits to power onsite equipment.

This covers high mains power and low voltage supply’s also Thrmal Camera testing and Ground Earth testing.

We come across many faults when we are called out to a site for the first time to look into a problem.

Just a few photos below are some installations and what we find when we are called out for the first time.

This our Net2 and Swing gate controller. Installed 2013This our Net2 and Swing gate controller. Installed 2013
These are our typical mains to low voltage door controller for door access. Installed 2017These are our typical mains to low voltage door controller for door access. Installed 2017
This is our Net2 in a riser cupboard these two power supply's contain four Net2 controllers for each floor of the building. We installed this on the third floor in multi floor office 2016This is our Net2 in a riser cupboard these two power supply's contain four Net2 controllers for each floor of the building. We installed this on the third floor in multi floor office 2016
This photo is what we found when we opened the door on this cabinet. No Earth and live wires exposed, also intercom wires just twisted together not solderedThis photo is what we found when we opened the door on this cabinet. No Earth and live wires exposed, also intercom wires just twisted together not soldered
We fixed the armoured cable and found where it was supplied from, then remade off the intercom wires. Soldered and insulated. Gate back up and workingWe fixed the armoured cable and found where it was supplied from, then remade off the intercom wires. Soldered and insulated. Gate back up and working
New 30W LED Flood Light on our aluminum bracket to light up entrace on a lorry parkNew 30W LED Flood Light on our aluminum bracket to light up entrace on a lorry park
Time to replace switch gear on 18x 37W fluorescent bulkheadsTime to replace switch gear on 18x 37W fluorescent bulkheads
New Choke, Starter, 4µF Capacitor and a BELL 37W 2-D 4-pin lampNew Choke, Starter, 4µF Capacitor and a BELL 37W 2-D 4-pin lamp
New Lithium Chargers and 32 amp 3-Phase Supplys all mounted on the wallNew Lithium Chargers and 32 amp 3-Phase Supplys all mounted on the wall
Existing Chargers and New 32 amp 3-Phase Supplys all mounted on the wallExisting Chargers and New 32 amp 3-Phase Supplys all mounted on the wall
3 Phase Load Ramp Controller damaged by forklift3 Phase Load Ramp Controller damaged by forklift
Ramp controller PCB installed in new enclosureRamp controller PCB installed in new enclosure
